HC-MFS23

HC-MFS23 is

In Stock Ships Today!

Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com

Rate the HC-MFS23

4.3/5 on 4 reviews

Product Details

Melservo HC Output Servo Motor 200W (HCMFS23)
Manufacturer: Mitsubishi
Series: MELSERVO HC

Product Description

The Mitsubishi HC-MFS23 (HCMFS23) is a Melservo HC output servo motor with a wattage of 200W. This servo motor has a normal speed of 3000rpm or it might also run on 4500rpm and the motor may be permitted for a short period of time to run at 5175rpm. The current that is evaluated for this servo motor is 1.5 Amp, but it also may be allowed to have a current of 5.0 Amp. The moment of inertia of the HC-MFS23 servo motor is 0.088 J(x10^-4kg x m^2) or 0.481 J(oz x in^2). The torque is 0.64 (N x m) or 90.6 (oz x in) but may be allowed to be aggrandized to ¬1.9 (N x m) or 269 (oz x in).

The HC-MFS23 output servo motor can link to many amplifiers of the MR-J2S series, the MR-J2S-20A, MR-J2S-20B, MR-J2S-20CP, and MR-J2S-20CL. These amplifiers can attach to this servo motor by a couple of ways. The first way is to connect the encoder cable which should be attached to the encoder of the HC-MFS23 servo motor to the CN2 port of the chosen amplifier. Then, to link with the power supply, the servo motor must link to the U, V, W screw terminal which are on any of the chosen amplifiers by utilizing the motor power cable.

The HC-MFS23 Melservo HC output servo motor is an ultra-low inertia motor and a small capacity motor, because it is part of the HC-MFS series. This type of motor can only attach to a pair of applications.

Here is the source material that may have been referenced:
http://dl.mitsubishielectric.com/dl/fa/document/catalog/servo/l03007/l03007d.pdf;
http://www.andreoniautomazione.it/mr-j2-super-catalogue_gb.pdf

Technical Specifications

Part Number: HC-MFS23 (HCMFS23)
Module Type: Output Servo Motor
Voltage: 120V
RPM: 3000
Output Wattage: 200W
Weight: 2.18lbs (0.99kg)

Related Parts

HC-SFS102B - Mitsubishi Melservo HC Servo Motor with Brake
MR-J3-70A - Mitsubishi Melservo MR-J3 Servo Amplifier
HC-SFS352 - Mitsubishi Melservo Servo Motor
MR-J4-70B - Mitsubishi Melservo MR-J4 Servo Amplifier

Shipping and Order Information

TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
Mitsubishi MELSERVO HC Shipping options vary by location. Call for an accurate quote.

Warranty

The Mitsubishi HC-MFS23 comes with a two year warranty.
A three year warranty is available. Please inquire for pricing.
