HC-MFS053B


Part Number - HC-MFS053B

HC-MFS053B is

In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the HC-MFS053B
5.0/5 on 2 reviews



Product Details

  • Melservo HC Servo Motor with Brake (HCMFS053B)
  • Manufacturer: Mitsubishi
  • Series: MELSERVO HC

Product Description

The Mitsubishi HC-MFS053B (HCMFS053B) is a Melservo HC series servo motor with a brake. The protective structure of this servo motor is the IP enclosure rating of IP55. The IP55 rating signifies that the servo motor is given a limited defense against dust that may negatively affect the motor. The rating also means it is preserved against damage done by direct spurts from low-pressure jets.

The HC-MFS053B servo motor with brake can be paired with the MR-J2S-10A servo amplifier. An encoder cable can concatenate the Servo Motor to the servo amplifier’s CN2 port; while a second cable can avail itself to the HC-MFS053B’s other connecting point in order to supply a connection to the U, V, and W terminal ports of the MR-J2S-10A.

The HC-MFS053B servo motor with brake is an ultra-low inertia motor. An ultra-low inertia motor is a small Servo Motor that functions well with high-frequency devices that are connected to a ball and screw integrant. The HC-MFS053B may be applied to inserters, bonders, mounters, in-circuit testers, label printers, and other mechanisms that comply with the following standards. The HC-MFS053B servo motor with brake has limitless regenerative breaking frequency as long as the effective torque is within rated torque range (N . m[oz . in]), which is 0.16Nm.

The HC-MFS053B servo motor has a voltage of 60V, the output wattage of 50W. The rated speed (rpm or r/min) of the servo motor is 3000rpm, while the maximum speed is 4000rpm. Although the HC-MFS053B servo motor with a brake can achieve a permissible instantaneous speed of 5175rpm.

Here is the source material that may have been referenced:
http://dl.mitsubishielectric.com/dl/fa/document/catalog/servo/l03007/l03007d.pdf
http://www.andreoniautomazione.it/mr-j2-super-catalogue_gb.pdf
https://www.enclosurecompany.com/ip-ratings-explained.php


Technical Specifications

Part Number: HC-MFS053B (HCMFS053B)
Module Type: Servo Motor with Brake
Voltage: 60V
RPM: 3000
Output Wattage: 50W
Weight: 1.65lbs (0.75kg)


Related Parts

HC-KFS053 - Mitsubishi Melservo HC Servo Motor (HCKFS053)
HC-KFS13 - Mitsubishi Melservo HC Servo Motor (HCKFS13)
HC-KFS13K - Mitsubishi Melservo HC Servo Motor with KEY (HCKFS13K)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Mitsubishi MELSERVO HC Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Mitsubishi HC-MFS053B comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
