HC-KFS23BK


Part Number - HC-KFS23BK

HC-KFS23BK is

In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the HC-KFS23BK
5.0/5 on 1 review



Product Details

  • Melservo HC Servo Motor with a Brake and Key (HCKFS23BK)
  • Manufacturer: Mitsubishi
  • Series: MELSERVO HC

Product Description

The Mitsubishi HC-KFS23BK (HCKFS23BK) is a Melservo HC series servo motor with a brake and key. The rated speed of the servo motor has is 3000rpm, but it is authorized to consistently run on 4500rpm, and still further, it may have a speed of 5175rpm. The current is 1.1 Amp which may at most be 3.4 Amp. The HC-KFS23BK servo motor has a torque of 0.64 (N x m) 90.6 (oz x in). Then the torque may be aggrandized to 1.9 (N x m) 269.0 (oz x in). The moment of inertia of the is 0.310 J(10^-4kg x m^2) 1.695 J(oz x in^2).

There are four amplifiers that are suitable for the HC-KFS23BK servo motor with brake key. These are the applicable amplifiers: the MR-J2S-20A, MR-J2S-20B, MR-J2S-20CP, and MR-J2S-20CL. The servo motor may be connected to the amplifier by attaching the encoder to the CN2 port. Also, the servo motor may connect to the amplifier’s power supply by linking to the three screw terminals, the U, V, and W terminals. The HC-KFS23BK servo motor is a low inertia motor that has a small capacity. There are many applications, mechanisms, and apparatuses that are apposite to the servo motor.

The HC-KFS23BK servo motor with a brake and key is given an enclosure rating of IP55. This mostly protects the servo motor from dust which may cause harm to it. It also guarded from spurts of water upon it from a spigot.

Here is the source material that may have been referenced:
http://dl.mitsubishielectric.com/dl/fa/document/catalog/servo/l03007/l03007d.pdf
http://www.andreoniautomazione.it/mr-j2-super-catalogue_gb.pdf
https://www.enclosurecompany.com/ip-ratings-explained.php


Technical Specifications

Part Number: HC-KFS23BK (HCKFS23BK)
Module Type: Servo Motor with a Brake and Key
Voltage: 118VAC
RPM: 3000
Output Wattage: 200W
Weight: 3.53lbs (1.6kg)


Related Parts

A1NCPU - Mitsubishi A Series CPUs Control Module
HC-UFS72K - Mitsubishi Melservo HC Servo Motor with KEY
MR-J4-100B - Mitsubishi Melservo MR-J4 Servo Amplifier



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Mitsubishi MELSERVO HC Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Mitsubishi HC-KFS23BK comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
