MDS-B-V1-45
MDS-B-V1-45 is
Available
Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.comProduct Details
- MDS Servo Drive 4.5kW (MDSBV145)
- Manufacturer: Mitsubishi
- Series: MDS Servo Drives
Product Description
The Mitsubishi MDS-B-V1-45 (MDSBV145) is a 4.5kW MDS series servo drive. The output of this servo drive has a voltage of 155V. Its estimated current is 28A, but the current is sanctioned to have a current streamlining at 85 Amp. There are divergent torques produced when differing motors used by the MDS-B-V1-45 155V servo drive. With the HA300N motor, the torque is 87 (N x m) or 893 (kg x cm); when the HA203N is utilized, the torque will be 56 (N x m) or 570 (kg x cm); if the HA500NL is utilized, the torque for the motor will be 72 (N x m) or 740 (kg x cm); and if the HA303NL is utilized, the torque can then be 60 (N x m) or 610 (oz x in).To create a nexus with the one of the selectable motors that was introduced above, the MDS-B-V1-45 servo drive must link to it this way. First, to link with the encoder of the chosen motor, the servo drive must attach with its CN2 port. Another connection that can be made by the CN3 port is with connectable section of any of the optional motors. The MDS-B-V1-45 servo drive can link to another connector used to transfer power to the motor by utilizing the four terminals that are situated at the bottom of it. Those terminals are the U, V, and W; the last terminal is meant to be grounded, and is therefore not given an epithet.
Here is the manual referenced:
https://s3.amazonaws.com/Icarus/DOCUMENTS/Mitsubishi_Manuals_432.pdf
Technical Specifications
Part Number: MDS-B-V1-45 (MDSBV145)Module Type: Servo Drive
Voltage: 155V
Output Wattage: 4.5kW
Weight: 13.23lbs (6.0kg)
Related Parts
F943GOT-LWD - Mitsubishi Operator InterfaceA4UCPU - Mitsubishi INPUT OUTPUT Controller
HC-UFS72K - Mitsubishi Melservo HC Servo Motor with KEY
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Mitsubishi MDS Servo Drives Shipping options vary by location. Call for an accurate quote.
Warranty
- The Mitsubishi MDS-B-V1-45 comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
