MDS-B-V1-35
MDS-B-V1-35 is
Available
Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.comProduct Details
- MDS Servo Drive 3.5kW (MDSBV135)
- Manufacturer: Mitsubishi
- Series: MDS Servo Drives
Product Description
The Mitsubishi MDS-B-V1-35 (MDSBV135) is a 3.5kW MDS series servo drive. This servo drives output has a current of 3.5kW and the greatest aggrandized current permissible is 57A with a voltage of 155V. The MDS-B-V1-35 servo drive has a torque generated by consonant with what is exploited. In the MDS-B-V1-35 servo drive the HA200N is used, the torque is 60 (kg x m) or 610 (kg x cm); with the HA103N then it is 40 (N x m) or 410 (kg x in). If the HA300NL is utilized, then the torque is 52 (N x m) or 530 (kg x in); and if the HA203NL is employed, the torque is 37 (N x m) or 380 (oz x in).To connect the MDS-B-V1-35 servo drive with one of the applicable motors which were mentioned in the antecedent paragraph, many connections must be made. The CN2 port can link to the motor by uniting it to its encoder. Then after that, the CN20 port can link with a connector on the motor, for a third connection, the four terminals at the bottom of the MDS-B-V1-35 servo drive, U, V, W, and a grounding terminal, can also link to the motors power supply.
Since the MDS-B-V1-35 servo drive has 1 axis, it will use its CN1B port that will connect to the CN1A port of the appropriate MDS-B-V2 servo drive. To create a system, the servo drives L+, L11, L-, and L21 terminals can attach to the same type of terminals in each succeeding drive.
Here is the manual referenced:
https://s3.amazonaws.com/Icarus/DOCUMENTS/Mitsubishi_Manuals_432.pdf
Technical Specifications
Part Number: MDS-B-V1-35 (MDSBV135)Module Type: Servo Drive
Voltage: 155V
Output Wattage: 3.5kW
Weight: 9.92lbs (4.5kg)
Related Parts
MR-J4-100B - Mitsubishi Melservo MR-J4 Servo AmplifierA0J2HCPU - Mitsubishi A Series CPUs A0J2 Controller
A4UCPU - Mitsubishi INPUT OUTPUT Controller
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Mitsubishi MDS Servo Drives Shipping options vary by location. Call for an accurate quote.
Warranty
- The Mitsubishi MDS-B-V1-35 comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
