MDS-B-CV-110


Part Number - MDS-B-CV-110

MDS-B-CV-110 is


Available


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the MDS-B-CV-110
5.0/5 on 2 reviews


Product Details

  • MDS Servo Drive with a Power Supply (MDSBCV110)
  • Manufacturer: Mitsubishi
  • Series: MDS Servo Drives

Product Description

The Mitsubishi MDS-B-CV-110 (MDSBCV110) is a 11kW MDS series servo drive with a power supply. The voltage that is effectuated in the output ranges from 270 to 311V. The power supply has a voltage that ranges from 200 to 230V but is allowed to waver between 170 to 243V. The frequency of the power supply is 50/60Hz, and it is permitted to oscillate between -3% to +3% of the original 50/60Hz in the MDS-B-CV-110 power supply. The greatest heat that may be produced is 130W.

The MDS-B-CV-110 servo drive with power supply has two ports with the first port being the CN9 port. Then there is the CN4 port that may link with the CN4 on the appropriate spindle drive that is a member of the proper series, either the MDS-B-SP-[].

There are also nine terminals located on the side and the bottom of the MDS-B-CV-110 servo drive with power supply. Four of these terminals, namely the L11, L21, L+, and L- can concatenate with the same four terminals on the spindle drive apposite to the power supply. The spindle drive can then attach to a servo drive that has two axes which can then link to another drive with one axis which creates an entire system. Then the MDS-B-CV-110 servo drive can link to the fan of a suitable spindle motor (previously linked with the spindle drive) by using the L11 and L21.The L1, L2, and L3 terminals are the terminals which outputs the voltage whose range is described in the first paragraph.

Here is the manual referenced:
https://s3.amazonaws.com/Icarus/DOCUMENTS/Mitsubishi_Manuals_432.pdf


Technical Specifications

Part Number: MDS-B-CV-110 (MDSBCV110)
Module Type: Servo Drive
Built-in Power Supply
Output Wattage: 11kW
Weight: 18.74lbs (8.5kg)


Related Parts

A1NCPU - Mitsubishi A Series CPUs Control Module
MR-J4-100B - Mitsubishi Melservo MR-J4 Servo Amplifier
HC-UFS72K - Mitsubishi Melservo HC Servo Motor with KEY



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Mitsubishi MDS Servo Drives Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Mitsubishi MDS-B-CV-110 comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
