FX1N-24MR-ES-UL
FX1N-24MR-ES-UL is
Available
Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.comProduct Details
- FX Series Input Output Control Module (FX1N24MRESUL)
- Manufacturer: Mitsubishi
- Series: FX Series
Product Description
The Mitsubishi FX1N-24MR-ES-UL (FX1N24MRESUL) is an input/output control module from the FX series. Like other constituent modules of the FX1N series, this module is very compatible with modules of other PLCs from the FX group; it is amiable to FX2N module due to sharing many of the FX2NS I/O and special function blocks. The programming structure of the FX1N-24MR-ES-UL is identical to that of the FX1S, while also sharing the same expansion board.The FX1N-24MR-ES-UL has a total of 24 points: 14 DC input points and 10 relay output points. The input voltage and frequency of this control module is 100-240VAC and 50/60Hz, and the power consumption wattage is 30W. The FX1N-24MR-ES-UL’s DC/AC voltage is 30VDC/240VAC and its output current is 2A.The dimensions of this module, in width times height times depth, is 90mm by 90mm by 75mm (3.54in by 3.54in by 2.95in) The FX1N-24MR-ES-UL control module itself weighs 0.99lb (0.45kg).
Some features of the FX1N-24MR-ES-UL are as what follows. The control module has a maintenance free, incorporated EEPROM user memory. The EEPROM user memory permits up to 8,000 PLC program steps. Extrinsic EEPROM memory cassettes can be utilized for PLC program storage. It also has an amalgamated serial interface that can allow for communication between an HMI and a personal computer.
Lastly, the FX1N-24MR-ES-UL should be in a room whose temperatures are between 32 and 131oF (0 to 50oC) or while in storage, the temperatures should be between -4 to 158 degrees Fahrenheit (-20 to 70 degrees Celsius) to keep the standard operations functioning properly.
Here is the source material referenced:
http://www.farnell.com/datasheets/1720026.pdf;
http://www.mitsubisih.com/pdfread/web/viewer.asp?ProductName=MITSUBISHI%20FX2N-128MR-ES/UL%20PDF%20datasheet&brandid=2&Downloadid=51541
Technical Specifications
Module Type: Input Output Control Module FX1N-24MR-ES-ULNumber of Points: 24pts.
Voltage Frequency: 100-240VAC, 50/60Hz
Weight: 0.99lbs (0.45kg)
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Mitsubishi FX Series Shipping options vary by location. Call for an accurate quote.
Warranty
- The Mitsubishi FX1N-24MR-ES-UL comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
