A62DA


Part Number - A62DA

A62DA is


Available


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the A62DA
4.5/5 on 2 reviews


Product Details

  • A Series Output Control Module (A62-DA)
  • Manufacturer: Mitsubishi
  • Series: A Series

Product Description

The Mitsubishi A62DA (A62-DA) is an A Series output control module with 2 channels. This control module has an output voltage when being set by the digital gambit of -2000 to 2000 and an output current output when set digitally between -1000 to 1000. The analogs voltage can range from -10 to 10VDC and for the current; the span is 4 to 20mA and -12mA to 20mA. So if the A62DA control module is digitally set to 2000, the voltage is 10V; if -2000, then -10V. If the control module is digitally set to 1000, the voltage is 5V with a current of 20mA; if -1000, then the voltage is -5V and the current is -12mA. Lastly, if the A62DA control module is digitally set to 0, the voltage will be 0V and the current will be 4mA.

The A62DA output control module has many external features. Primarily, there lie on the face twenty terminals. Terminals 1 and 2 are test terminals, terminals 4 and 5 are the terminals that have inputs of 24VDC, terminals 8 to 11 participate in channel 1, and terminals 13 to 16 are members of channel 2. Terminals 8 and 13 are V+, 9 and 14 are V-, 10 and 15 are I+, and 11 and 16 are I-. The channels of the A62DA module are chosen by the channel switch on it. Below that switch is a switch that can activate a gain, a set, or an offset gauge worth. There is also another switch that is labeled ‘up’ in order to increase the current and vice-versa with the ‘down’ label.

Here is the source material referenced:
http://www.mitsubisih.com/pdfread/web/viewer.asp?file=/PDFCatalogEn/A_QNA-EN.PDF&productname=A62DA%20Model%20selection%20sample&brandid=2&DownloadID=0


Technical Specifications

Part Number: A62DA (A62-DA)
Module Type: Output Control Module
Number of Output Channels: 2
Weight: 1.1lbs (0.5kg)


Related Parts

A1SX10 - Mitsubishi A1SX DISCRETE Control Module
A1SX20 - Mitsubishi A1SX DISCRETE Control Module
A1SY13A - Mitsubishi A1SY DISCRETE Control Module



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Mitsubishi A Series Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Mitsubishi A62DA comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
