A970GOT-TBA-B
A970GOT-TBA-B is
Available
Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.comProduct Details
- A900GOT Touchscreen Operator Interface (A970GOTTBAB)
- Manufacturer: Mitsubishi
- Series: A900GOT
Product Description
The Mitsubishi A970GOT-TBA-B (A970GOTTBAB) is a A900GOT touchscreen operator interface. This operator interface has a power supply that can span from 100-240VAC and may operate at a greater voltage span of 85 to 264VAC. The complimentary frequency is 50/60Hz that may waver between -3% and 3%. The inrush current of the A970GOT-TBA-B operator interface is 40 Amp at most, and its load voltage is 264VAC.The dimension of the A900GOT touchscreen are 297mm by 208mm by 46mm which is 11.7in by 8.2in by 1.81in. Also the panel is measured to be 289mm by 200mm that is in inches, 11.38in by 7.88in. The screen size of the A970GOT-TBA-B operator interface is 211mm by 158mm which is also 8.31in by 6.23in. There may be sixteen colors which may appear on the interface screen and there are 640 dots by 480 dots which make up this screen. The screen is made up of TFT LCD.
On the A970GOT-TBA-B operator interface, there are multiple ports and slots, and there is even a terminal block. The five ports are RS-232C, printer, memory card, a port for modules that are utilized for communication, and a port for a module that may be permitted to attach with the A970GOT-TBA-B operator interface. The RS-232C port may link with a PC and there are also many slots, one that is used for one of two boards, memory or communication. The terminal block on the interface may be for inputs or outputs.
The source material that may have been referenced:
https://dl.mitsubishielectric.com/dl/fa/document/manual/got/ib80032e/ib80032eh.pdf
Technical Specifications
Part Number: A970GOT-TBA-B (A970GOTTBAB)Module Type: Touchscreen Operator Interface
Voltage/Frequency: 100-240VAC, 50/60Hz
Weight: 3.96lbs (1.8kg)
Related Parts
A-985-GOT-TBA-EU - Mitsubishi Operator Interface Touchscreen (A985GOTTBAEU)A4UCPU - Mitsubishi INPUT OUTPUT Controller
A970GOTLBA - Mitsubishi 10.4 INCH Monochrome Operator Interface
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Mitsubishi A900GOT Shipping options vary by location. Call for an accurate quote.
Warranty
- The Mitsubishi A970GOT-TBA-B comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
TRW Electric & Supply Company is a global automation supplier. We deliver reliable new and refurbished parts at a great value. Our product focus is Omron and Mitsubishi products, but we have been able to provide our customers with solutions from other manufacturers as well. Our goal is to supply the automation industry with the best service and pricing, and of course conduct business with a high level of integrity.
A Mitsubishi Authorized Distributor for A900GOT is not the only source for Mitsubishi products. Many of the Mitsubishi products have been discontinued and therefore are no longer available from authorized suppliers. TRW Electric & Supply has many new and refurbished Mitsubishi A900GOT parts available for purchase.
