A1SY10
A1SY10 is
Available
Contact us to place an order or request a quote:
1-800-479-8084 | sales@trwsupply.comProduct Details
- A Series Output Control Module (A1S-Y10)
- Manufacturer: Mitsubishi
- Series: A Series
Product Description
The Mitsubishi A1SY10 (A1S-Y10) is a A series output control module with 16 points. The control module has a insulation method is photocoupler (or otherwise known as an optocoupler or an optical isolator) which transmits electrical signal between two sequestered circuits via infrared light through a diaphanous insulator. There is a LED indicator imbedded in the A1SY10 to signify it is operating. The weight of the A series output control module is 0.55 pounds (0.25kg).The A1SY10 output control module has 16 points with a rated switching for its voltage and current of 24V DC/2 AMP or 240V AC/2 AMP. The minimum switching load of this output control module is 5VDC and 1mA; the maximum switching voltage, 125VDC or 264V AC. The A1SY10's maximum switching frequency is 3600 times per hour. The internal current consumption with 5V DC is 120mA when all points are on. The time is takes for the output control module to respond is less than 10ms when turning it on and less than 12ms when turning it off.
The A1SY10 control module will transform digital values to output values, after this is done it outputs the voltage and current. As one out of six A1S output control modules, it acts as a reliable interface between the A1S PLC system (to which it outputs to)and other output mechanisms with its 20 point terminal block connector. Wire sizes that are apposite for the Mitsubishi A1SY10's M3.5 x 7 screws, which are in the terminal block connectors, can only extend from 0.75 to 1.25mm2 in diameter.
Here is the source material referenced:
http://suport.siriustrading.ro/02.DocArh/01.PLC/03.Modulare/05.MELSEC%20AnS,QnAS/02.Module%20de%20extensie%20DIO/AnS-Module%20IO%20-%20User's%20Manual%20IB(NA)-66541-S%20(10.14).pdf
Technical Specifications
Part Number: A1SY10 (A1S-Y10)Module Type: Control Module
Number of Output Points: 16
Weight: 0.55lbs (0.25kg)
Related Parts
A1SX10 - Mitsubishi A1SX DISCRETE Control ModuleA1SX20 - Mitsubishi A1SX DISCRETE Control Module
A1SY13A - Mitsubishi A1SY DISCRETE Control Module
Shipping and Order Information
- TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
- Mitsubishi A Series Shipping options vary by location. Call for an accurate quote.
Warranty
- The Mitsubishi A1SY10 comes with a two year warranty.
- A three year warranty is available. Please inquire for pricing.
