A1S64AD

A1S64AD is

In Stock Ships Today!

Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com

Rate the A1S64AD

4.0/5 on 1 review

Product Details

A Series Input Output Control Module (A1S-64AD)
Manufacturer: Mitsubishi
Series: A Series

Product Description

The Mitsubishi A1S64AD (A1S-64AD) is an A series input output control module. This control module analog has a voltage that spans -10 to 10VDC and the current is able to span from -20 to 20mA. The input that is digital has the highest setting range of 1/4000, 1/8000, or 1/12000. The digital value remains the same when the analog is 10V, or is the same value in the negative if the analog is -10. In the A1S64AD control module, if the voltage is +5V or the current is +20ma, the digital input is half the original positive value; when the voltage is -5V or the current is -20mA, then the digital input is half the negative value. If the total analog is zero, the digital value will also be zero.

There are only four channels in the A1S64AD input output control module each channel is composed of an I+, COM, and SLD terminal. Connections to these channels are made by the twenty screws on the screw terminal block. One screw that is utilized for V+ intersperses each channel from the other and to separate channel 1 from the testing terminal that is terminal 1. The screw terminals that compose the A1S64AD control module’s channels are these: terminals 3 to 5 make up channel 1, terminals 7 to 9 create channel 2, channel 3 is constituted by terminals 11 to 13, and channel 4 is formed by terminals 15 to 17. Channels may be selected by the channel rotary switch that may be revolved in order to choose the desired channel.

Here is the source material that may have been referenced:
https://manualzz.com/doc/7082729/a-d-converter-module-type-a1s64ad-user-s-manual--hardware-

Technical Specifications

Part Number: A1S64AD (A1S-64AD)
Module Type: Input Output Control Module
Number of Input Output Points: 32
Weight: 0.55lb (0.25kg)

Shipping and Order Information

TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
Mitsubishi A Series Shipping options vary by location. Call for an accurate quote.

Warranty

The Mitsubishi A1S64AD comes with a two year warranty.
A three year warranty is available. Please inquire for pricing.
